Fitting genotype by environment models in sommer

The sommer package was developed to provide R users with a flexible univariate and multivariate linear mixed-model solver. The current package provides two complementary REML formulations. The mmes() function uses Henderson’s mixed model equations and a sparse Average Information REML algorithm: the mixed-model coefficient matrix is factorized with sparse LDLT methods, selected inverse elements required by REML calculations can be obtained with Takahashi sparse-inverse recursions, and the factorization is reused for mixed-model solutions and variance-parameter derivatives. The mmer() function uses the marginal-covariance MNR formulation, in which REML calculations are organized around the observation covariance matrix $V$ and the REML projection matrix $P$ . The relative efficiency of the two formulations depends on model dimensions, sparsity, and covariance structure rather than only on whether $p>n$ or $n>p$ . The core numerical algorithms are coded in C++ using Armadillo and Eigen. The package allows users to specify flexible variance-covariance structures for random and residual effects and to obtain quantities such as REML variance-covariance estimates, BLUPs, BLUEs, residuals, fitted values, and prediction error variance information.

The purpose of this vignette is to show how to fit different genotype by environment (GxE) models using the sommer package:

Single environment model
Multienvironment model: Main effect model
Multienvironment model: Diagonal model (DG)
Multienvironment model: Compund symmetry model (CS)
Multienvironment model: Unstructured model (US)
Multienvironment model: Random regression model (RR)
Multienvironment model: Other covariance structures for GxE
Multienvironment model: Finlay-Wilkinson regression
Multienvironment model: Factor analytic (reduced rank) model (FA)
Two stage analysis

When the breeder decides to run a trial and apply selection in a single environment (whether because the amount of seed is a limitation or there’s no availability for a location) the breeder takes the risk of selecting material for a target population of environments (TPEs) using an environment that is not representative of the larger TPE. Therefore, many breeding programs try to base their selection decision on multi-environment trial (MET) data. Models could be adjusted by adding additional information like spatial information, experimental design information, etc. In this tutorial we will focus mainly on the covariance structures for GxE and the incorporation of relationship matrices for the genotype effect.

1) Single environment model

A single-environment model is the one that is fitted when the breeding program can only afford one location, leaving out the possible information available from other environments. This will be used to further expand to GxE models.

library(sommer)

## Loading required package: Matrix

## Loading required package: MASS

## Loading required package: crayon

## Loading required package: enhancer

data(DT_example, package="enhancer")
DT <- DT_example
A <- A_example

Ai <- solve(A)
Ai <- as(as(as( Ai,  "dMatrix"), "generalMatrix"), "CsparseMatrix")
attr(Ai, "inverse")=TRUE

ansSingle <- mmes(Yield~1,
              random= ~ vsm(ism(Name), Gu=Ai),
              rcov= ~ units,
              data=DT, verbose = FALSE)

## Solver selected: ldlt

summary(ansSingle)

## ============================================================
##          Multivariate Linear Mixed Model fit by  REML
## **********************  sommer 4.4  **********************
## ============================================================
##          logLik      AIC      BIC Method Converge
## Value -81.41893 164.8379 168.0582     AI     TRUE
## ============================================================
## Variance-Covariance components:
##                      term parameter estimate StdError Zratio
## 1 vsm(ism(Name), Gu = Ai)    sigma2    6.533    2.184  2.991
## 2         vsm(ism(units))    sigma2   13.865    1.629  8.513
## ============================================================
## Fixed effects:
##           Estimate Std.Error t.value
## Intercept    11.74        NA      NA
## ============================================================
## Use the '$' sign to access results and parameters

In this model, the random term is the germplasm effect (here called Name). For the sake of example, a relationship structure among the levels of Name is supplied through Gu. In the code above Ai is the sparse precision matrix corresponding to the relationship matrix A, and attr(Ai, "inverse")=TRUE tells sommer that the supplied matrix is already in precision form. More generally, a non-diagonal relationship structure can be used to model covariance among genotype levels.

2) MET: main effect model

A multi-environment model is the one that is fitted when the breeding program can afford more than one location. The main effect model assumes that GxE doesn’t exist and that the main genotype effect plus the fixed effect for environment is enough to predict the genotype effect in all locations of interest.

ansMain <- mmes(Yield~Env,
              random= ~ vsm(ism(Name), Gu=Ai),
              rcov= ~ units,
              data=DT, verbose = FALSE)

## Solver selected: ldlt

summary(ansMain)

## ============================================================
##          Multivariate Linear Mixed Model fit by  REML
## **********************  sommer 4.4  **********************
## ============================================================
##          logLik      AIC      BIC Method Converge
## Value -38.73391 83.46782 93.12888     AI     TRUE
## ============================================================
## Variance-Covariance components:
##                      term parameter estimate StdError Zratio
## 1 vsm(ism(Name), Gu = Ai)    sigma2    4.858   1.4994  3.240
## 2         vsm(ism(units))    sigma2    8.107   0.9575  8.467
## ============================================================
## Fixed effects:
##            Estimate Std.Error t.value
## Intercept    16.385        NA      NA
## EnvCA.2012   -5.688        NA      NA
## EnvCA.2013   -6.218        NA      NA
## ============================================================
## Use the '$' sign to access results and parameters

3) MET: diagonal model (DG)

A multi-environment model is fitted when observations are available from more than one environment. The diagonal GxE model allows the genetic variance to differ among environments while constraining the genetic covariance between different environments to zero. In the current vsm() parameterization, dsm(Env) is a normalized diagonal covariance factor: one product-level variance scale is estimated by vsm() and the remaining diagonal parameters are relative variance ratios. Thus the model has an environment-specific genetic variance without estimating cross-environment genetic covariances. The fixed environment effect and the environment-specific genotype BLUP are then combined to predict performance in each environment.

ansDG <- mmes(Yield~Env,
              random= ~ vsm(dsm(Env),ism(Name), Gu=Ai),
              rcov= ~ units,
              data=DT, verbose = FALSE)

## Solver selected: ldlt

summary(ansDG)

## ============================================================
##          Multivariate Linear Mixed Model fit by  REML
## **********************  sommer 4.4  **********************
## ============================================================
##          logLik      AIC      BIC Method Converge
## Value -27.18127 60.36254 70.02361     AI     TRUE
## ============================================================
## Variance-Covariance components:
##                                term         parameter estimate StdError Zratio
## 1 vsm(dsm(Env), ism(Name), Gu = Ai) variance[CA.2011]   17.472   6.0888  2.869
## 2 vsm(dsm(Env), ism(Name), Gu = Ai) variance[CA.2012]    5.339   1.7909  2.981
## 3 vsm(dsm(Env), ism(Name), Gu = Ai) variance[CA.2013]    7.886   2.5493  3.093
## 4                   vsm(ism(units))            sigma2    4.381   0.6514  6.724
## ============================================================
## Fixed effects:
##            Estimate Std.Error t.value
## Intercept    16.621        NA      NA
## EnvCA.2012   -5.958        NA      NA
## EnvCA.2013   -6.662        NA      NA
## ============================================================
## Use the '$' sign to access results and parameters

4) MET: compund symmetry model (CS)

A multi-environment model is fitted when observations are available from more than one environment. In the code below, compound-symmetry-like GxE behavior is represented by two independent random terms: a genotype main effect shared across environments and an environment-by-genotype deviation. Their covariance contribution is the sum of the two random-effect covariance matrices. Under the identity structures used here this implies a common covariance between observations on the same genotype in different environments, while the GxE deviation adds environment-specific variance. The fixed environment effect, genotype main-effect BLUP, and genotype-by-environment BLUP together describe performance in each environment.

E <- diag(length(unique(DT$Env)));rownames(E) <- colnames(E) <- unique(DT$Env)
Ei <- solve(E)
Ai <- solve(A)
EAi <- kronecker(Ei,Ai, make.dimnames = TRUE)
Ei <- as(as(as( Ei,  "dMatrix"), "generalMatrix"), "CsparseMatrix")
Ai <- as(as(as( Ai,  "dMatrix"), "generalMatrix"), "CsparseMatrix")
EAi <- as(as(as( EAi,  "dMatrix"), "generalMatrix"), "CsparseMatrix")
attr(Ai, "inverse")=TRUE
attr(EAi, "inverse")=TRUE
ansCS <- mmes(Yield~Env,
              random= ~ vsm(ism(Name), Gu=Ai) + vsm(ism(Env:Name), Gu=EAi),
              rcov= ~ units,
              data=DT, verbose = FALSE)

## Adding 29 additional Gu levels to the main-effect model matrix: CA.2013:CO05061-2P, CA.2013:AC01151-5W, CA.2013:MSS165-2Y, CA.2013:NY148, CA.2013:W8539-2Y, CA.2013:W8615-5, CA.2013:MSR148-4, CA.2013:CO00270-7W, CA.2011:Manistee(MSL292-A), CA.2011:AC05153-1W ...

## Solver selected: ldlt

summary(ansCS)

## ============================================================
##          Multivariate Linear Mixed Model fit by  REML
## **********************  sommer 4.4  **********************
## ============================================================
##          logLik      AIC      BIC Method Converge
## Value -26.28507 58.57015 68.23121     AI     TRUE
## ============================================================
## Variance-Covariance components:
##                           term parameter estimate StdError Zratio
## 1      vsm(ism(Name), Gu = Ai)    sigma2    3.684   1.6274  2.263
## 2 vsm(ism(Env:Name), Gu = EAi)    sigma2    5.171   1.4764  3.502
## 3              vsm(ism(units))    sigma2    4.367   0.6487  6.732
## ============================================================
## Fixed effects:
##            Estimate Std.Error t.value
## Intercept    16.496        NA      NA
## EnvCA.2012   -5.777        NA      NA
## EnvCA.2013   -6.380        NA      NA
## ============================================================
## Use the '$' sign to access results and parameters

5) MET: unstructured model (US)

The unstructured GxE model allows a distinct genetic variance for each environment and a distinct genetic covariance for every pair of environments. In the current vsm() architecture, usm(Env) is represented by a normalized Cholesky covariance factor and vsm() supplies the single product-level variance scale. This parameterization guarantees positive definiteness for admissible working parameters while retaining the flexibility of an unstructured covariance matrix. Because the number of covariance-shape parameters grows rapidly with the number of environments, these models can still be statistically weakly identified or computationally demanding. The fixed environment effect and the correlated environment-specific genotype BLUPs are used to predict performance in each environment.

ansUS <- mmes(Yield~Env,
              random= ~ vsm(usm(Env),ism(Name), Gu=Ai),
              rcov= ~ units,
              data=DT, verbose = FALSE)

## Solver selected: ldlt

summary(ansUS)

## ============================================================
##          Multivariate Linear Mixed Model fit by  REML
## **********************  sommer 4.4  **********************
## ============================================================
##          logLik      AIC      BIC Method Converge
## Value -20.34919 46.69838 56.35945     AI     TRUE
## ============================================================
## Variance-Covariance components:
##                                term                   parameter estimate
## 1 vsm(usm(Env), ism(Name), Gu = Ai)           variance[CA.2011]  15.9857
## 2 vsm(usm(Env), ism(Name), Gu = Ai) covariance[CA.2012,CA.2011]   6.1692
## 3 vsm(usm(Env), ism(Name), Gu = Ai) covariance[CA.2013,CA.2011]   6.3638
## 4 vsm(usm(Env), ism(Name), Gu = Ai)           variance[CA.2012]   5.2744
## 5 vsm(usm(Env), ism(Name), Gu = Ai) covariance[CA.2013,CA.2012]   0.3746
## 6 vsm(usm(Env), ism(Name), Gu = Ai)           variance[CA.2013]   7.6896
## 7                   vsm(ism(units))                      sigma2   4.3859
##   StdError Zratio
## 1   5.2288 3.0573
## 2   2.4710 2.4966
## 3   2.8812 2.2087
## 4   1.7708 2.9786
## 5   1.5598 0.2402
## 6   2.4698 3.1134
## 7   0.6525 6.7216
## ============================================================
## Fixed effects:
##            Estimate Std.Error t.value
## Intercept    16.341        NA      NA
## EnvCA.2012   -5.696        NA      NA
## EnvCA.2013   -6.286        NA      NA
## ============================================================
## Use the '$' sign to access results and parameters

6) MET: random regression model

A random regression model represents environmental response with a continuous covariate or a set of basis functions, here Legendre polynomials of the numeric environment index. Genotype-specific coefficients on these basis functions describe reaction norms across environments. The covariance structure assigned to the basis coefficients determines how the random intercept, slopes, and higher-order coefficients vary and covary. Consequently, the number of covariance parameters depends both on the polynomial order and on the covariance structure placed on the basis coefficients.

library(orthopolynom)
DT$EnvN <- as.numeric(as.factor(DT$Env))

ansRR <- mmes(Yield~Env,
              random= ~ vsm(dsm(leg(EnvN,1)),ism(Name)),
              rcov= ~ units,
              data=DT, verbose = FALSE)

## Solver selected: ldlt

summary(ansRR)

## ============================================================
##          Multivariate Linear Mixed Model fit by  REML
## **********************  sommer 4.4  **********************
## ============================================================
##          logLik      AIC      BIC Method Converge
## Value -33.84286 73.68572 83.34679     AI     TRUE
## ============================================================
## Variance-Covariance components:
##                                term      parameter estimate StdError Zratio
## 1 vsm(dsm(leg(EnvN, 1)), ism(Name)) variance[leg0]   10.389   3.0820  3.371
## 2 vsm(dsm(leg(EnvN, 1)), ism(Name)) variance[leg1]    2.081   0.9939  2.094
## 3                   vsm(ism(units))         sigma2    6.296   0.8548  7.365
## ============================================================
## Fixed effects:
##            Estimate Std.Error t.value
## Intercept    16.541        NA      NA
## EnvCA.2012   -5.832        NA      NA
## EnvCA.2013   -6.472        NA      NA
## ============================================================
## Use the '$' sign to access results and parameters

In addition, an unstructured, diagonal or other variance-covariance structure can be put on top of the polynomial model:

library(orthopolynom)
DT$EnvN <- as.numeric(as.factor(DT$Env))

ansRR <- mmes(Yield~Env,
              random= ~ vsm(usm(leg(EnvN,1)),ism(Name)),
              rcov= ~ units,
              data=DT, verbose = FALSE)

## Solver selected: ldlt

summary(ansRR)

## ============================================================
##          Multivariate Linear Mixed Model fit by  REML
## **********************  sommer 4.4  **********************
## ============================================================
##          logLik      AIC      BIC Method Converge
## Value -31.70935 69.41871 79.07978     AI     TRUE
## ============================================================
## Variance-Covariance components:
##                                term             parameter estimate StdError
## 1 vsm(usm(leg(EnvN, 1)), ism(Name))        variance[leg0]   10.788   3.2124
## 2 vsm(usm(leg(EnvN, 1)), ism(Name)) covariance[leg1,leg0]   -2.428   1.3610
## 3 vsm(usm(leg(EnvN, 1)), ism(Name))        variance[leg1]    2.288   1.0754
## 4                   vsm(ism(units))                sigma2    6.259   0.8533
##   Zratio
## 1  3.358
## 2 -1.784
## 3  2.128
## 4  7.335
## ============================================================
## Fixed effects:
##            Estimate Std.Error t.value
## Intercept    16.501        NA      NA
## EnvCA.2012   -5.791        NA      NA
## EnvCA.2013   -6.476        NA      NA
## ============================================================
## Use the '$' sign to access results and parameters

7) Other GxE covariance structures

Many structured covariance models can be used for GxE when their assumptions are appropriate for the ordering or relationship among environments. In the example below csm(Env) specifies a homogeneous correlation structure for the environment covariance factor. Other available structures, such as autoregressive models for meaningfully ordered environments, can be substituted within the same vsm() product architecture.

ansAR1 <- mmes(Yield~Env,
              random= ~ vsm(csm(Env),ism(Name)),
              rcov= ~ units,
              data=DT, verbose = FALSE)

## Solver selected: ldlt

summary(ansAR1)

## ============================================================
##          Multivariate Linear Mixed Model fit by  REML
## **********************  sommer 4.4  **********************
## ============================================================
##         logLik     AIC      BIC Method Converge
## Value -26.2851 58.5702 68.23127     AI     TRUE
## ============================================================
## Variance-Covariance components:
##                       term parameter estimate StdError Zratio
## 1 vsm(csm(Env), ism(Name))  variance   8.8448   1.7868  4.950
## 2 vsm(csm(Env), ism(Name))       rho   0.4156   0.1463  2.841
## 3          vsm(ism(units))    sigma2   4.3700   0.6494  6.729
## ============================================================
## Fixed effects:
##            Estimate Std.Error t.value
## Intercept    16.496        NA      NA
## EnvCA.2012   -5.777        NA      NA
## EnvCA.2013   -6.381        NA      NA
## ============================================================
## Use the '$' sign to access results and parameters

8) Finlay-Wilkinson regression

data(DT_h2, package="enhancer")
DT <- DT_h2

## build the environmental index
ei <- aggregate(y~Env, data=DT,FUN=mean)
colnames(ei)[2] <- "envIndex"
ei$envIndex <- ei$envIndex - mean(ei$envIndex,na.rm=TRUE) # center the envIndex to have clean VCs
ei <- ei[with(ei, order(envIndex)), ]

## add the environmental index to the original dataset
DT2 <- merge(DT,ei, by="Env")

# numeric by factor variables like envIndex:Name can't be used in the random part like this
# they need to come with the vsm() structure
DT2 <- DT2[with(DT2, order(Name)), ]
mix2 <- mmes(y~ envIndex,
             random=~ Name + vsm(ism(envIndex),ism(Name)), data=DT2,
             rcov=~vsm(dsm(Name),ism(units)),
             nIters = 50, verbose = FALSE
)

## Solver selected: ldlt

# summary(mix2)$varcomp

b=mix2$uList$`vsm(ism(envIndex), ism(Name` # adaptability (b) or genotype slopes
mu=mix2$uList$`vsm(ism(Name`# general adaptation (mu) or main effect
e=sqrt(summary(mix2)$varcomp[-c(1:2),"estimate"]) # error variance for each individual

## general adaptation (main effect) vs adaptability (response to better environments)
plot(mu[,1]~b[,1], ylab="general adaptation", xlab="adaptability")
text(y=mu[,1],x=b[,1], labels = rownames(mu), cex=0.5, pos = 1)

## prediction across environments
Dt <- mix2$Dtable
Dt[1,"average"]=TRUE
Dt[2,"include"]=TRUE
Dt[3,"include"]=TRUE

mix2 <- postPEV(mix2, mode=2)
pp <- predict(mix2,Dtable = Dt, D="Name")
preds <- pp$pvals
# preds[with(preds, order(-predicted.value)), ]
## performance vs stability (deviation from regression line)
plot(preds[,2]~e, ylab="performance", xlab="stability")
text(y=preds[,2],x=e, labels = rownames(mu), cex=0.5, pos = 1)

9) Factor analytic and reduced rank models

When the number of environments is large, a fully unstructured genetic covariance requires $q(q+1)/2$ covariance parameters for $q$ environments and can become weakly identified relative to the available information. Reduced-rank and factor-analytic representations provide a more parsimonious alternative. In the first implementation below, we show the use of the factor analytic structure fam() where loadings and specific variances are estimated through REML and produce predictions.

data(DT_h2, package="enhancer")
DT <- DT_h2
DT=DT[with(DT, order(Env)), ]
head(DT)

##          Name     Env Loc Year     Block  y
## 67   MSL007-B CA.2011  CA 2011 CA.2011.2  5
## 105  MSL007-B CA.2011  CA 2011 CA.2011.1  6
## 308  MSK061-4 CA.2011  CA 2011 CA.2011.2  9
## 393  MSK061-4 CA.2011  CA 2011 CA.2011.1 10
## 469 MSR169-8Y CA.2011  CA 2011 CA.2011.1 11
## 471     NY148 CA.2011  CA 2011 CA.2011.1 11

indNames <- na.omit(unique(DT$Name))
A <- diag(length(indNames))
rownames(A) <- colnames(A) <- indNames

# factor analytic model with 2 factors
ansFA2 <- mmes(y~Env,
               random=~vsm( fam(Env, 2) , ism(Name)) ,
               rcov=~units,
               nIters = 100, verbose = FALSE,
               data=DT)

## Solver selected: ldlt

Dt <- ansFA2$Dtable; Dt

##     type                        term include average levels
## 1  fixed                           1   FALSE   FALSE   NULL
## 2  fixed                         Env   FALSE   FALSE   NULL
## 3 random vsm(fam(Env, 2), ism(Name))   FALSE   FALSE   NULL

Dt[1:2,"average"]=TRUE
Dt[3,c("average","include")]=TRUE

ppfa <- predict(ansFA2, D="Env:Name", Dtable = Dt)
head(ppfa$pvals)

##                            Env:Name predicted.value std.error        pev
## CA.2011:A01143-3C CA.2011:A01143-3C        17.72739 1.3831466 1.91309448
## CA.2012:A01143-3C CA.2012:A01143-3C        12.02340 1.1429048 1.30623143
## CA.2013:A01143-3C CA.2013:A01143-3C        19.44638 1.2267732 1.50497256
## FL.2011:A01143-3C FL.2011:A01143-3C        11.69483 0.5023346 0.25234003
## FL.2012:A01143-3C FL.2012:A01143-3C        11.70725 0.2991085 0.08946588
## FL.2013:A01143-3C FL.2013:A01143-3C        11.78597 0.2808610 0.07888292
##                        var.u
## CA.2011:A01143-3C 13.5928310
## CA.2012:A01143-3C  3.9902740
## CA.2013:A01143-3C  6.2851780
## FL.2011:A01143-3C  1.4129515
## FL.2012:A01143-3C  0.2908999
## FL.2013:A01143-3C  0.0000000

If needed, loadings and factor scores can be extracted with the loadings_mmes() and scores_mmes() functions. The second implementation below uses the reduced rank implementation available with the rrm() function to estimate loadings through REML and we use a diagonal term (dsm) to fit the environment specific variances.

# reduced rank model with 2 factors
ansRR2 <- mmes(y~Env, henderson=TRUE,
              random=~vsm( rrm(Env, 2) , ism(Name)) + # rr
                vsm(dsm(Env), ism(Name)), # diag
              rcov=~units,
              nIters = 100, verbose = FALSE,
              data=DT)

## Solver selected: ldlt

Dt <- ansRR2$Dtable; Dt

##     type                        term include average levels
## 1  fixed                           1   FALSE   FALSE   NULL
## 2  fixed                         Env   FALSE   FALSE   NULL
## 3 random vsm(rrm(Env, 2), ism(Name))   FALSE   FALSE   NULL
## 4 random    vsm(dsm(Env), ism(Name))   FALSE   FALSE   NULL

Dt[1:2,"average"]=TRUE
Dt[3:4,c("average","include")]=TRUE

pprr <- predict(ansRR2, D="Env:Name", Dtable = Dt)
head(pprr$pvals)

##                            Env:Name predicted.value std.error        pev
## CA.2011:A01143-3C CA.2011:A01143-3C        17.72535 1.3837243 1.91469298
## CA.2012:A01143-3C CA.2012:A01143-3C        12.02355 1.1430456 1.30655332
## CA.2013:A01143-3C CA.2013:A01143-3C        19.44686 1.2266952 1.50478120
## FL.2011:A01143-3C FL.2011:A01143-3C        11.69112 0.4982976 0.24830054
## FL.2012:A01143-3C FL.2012:A01143-3C        11.70628 0.3095111 0.09579710
## FL.2013:A01143-3C FL.2013:A01143-3C        11.78601 0.2805777 0.07872383
##                        var.u
## CA.2011:A01143-3C 13.5699632
## CA.2012:A01143-3C  3.9843518
## CA.2013:A01143-3C  6.2721962
## FL.2011:A01143-3C  1.4156538
## FL.2012:A01143-3C  0.2910462
## FL.2013:A01143-3C  0.0000000

# compare
plot(ppfa$pvals[,"predicted.value"],pprr$pvals[,"predicted.value"])

Last but not least, it is possible to avoid the estimation of loadings by defining fixed loadings as covariates of a random regression coming from a diagonal model that uses the GxE predictions to derive Sigma and the fixed loadings.

# fit diagonal model first to produce H matrix
ansDG <- mmes(y~Env, henderson=TRUE,
              random=~ vsm(dsm(Env), ism(Name)),
              rcov=~units, nIters = 100,
              data=DT, verbose = FALSE)

## Solver selected: ldlt

H0 <- ansDG$uList$`vsm(dsm(Env), ism(Name))` # GxE table

# # reduced rank model
# ansFA <- mmes(y~Env, henderson=TRUE,
#               random=~vsm( usm(rrmat(Env, H = H0, nPC = 2)) , ism(Name)) + # rr
#                 vsm(dsm(Env), ism(Name)), # diag
#               rcov=~units,
#               # we recommend giving more iterations to these models
#               nIters = 100, verbose = FALSE,
#               # we recommend giving more EM iterations at the beggining
#               data=DT)
#
# vcFA <- ansFA$theta[[1]]
# vcDG <- ansFA$theta[[2]]
#
# loadings=with(DT, rrmat(Env, nPC = 2, H = H0, returnGamma = TRUE) )$Gamma
# scores <- ansFA$uList[[1]]
#
# vcUS <- loadings %*% vcFA %*% t(loadings)
# G <- vcUS + vcDG
# # colfunc <- colorRampPalette(c("steelblue4","springgreen","yellow"))
# # hv <- heatmap(cov2cor(G), col = colfunc(100), symm = TRUE)
#
# uFA <- scores %*% t(loadings)
# uDG <- ansFA$uList[[2]]
# u <- uFA + uDG
#
# plot(ppfa$pvals[,"predicted.value"],as.vector(t(u)))
# plot(as.vector(t(u)),pprr$pvals[,"predicted.value"])

10) Two stage analysis

In two-stage analyses, a first-stage mixed model is commonly fitted to account for experimental-design and field variation while treating the entry effects of interest as fixed, producing adjusted entry means (BLUEs or EMMs). Their estimation-error covariance should be carried into the second stage rather than treating the adjusted means as independent observations with equal precision. In the example below, computeCi = 2 requests the complete coefficient-matrix inverse after fitting each first-stage model; the fixed-effect block is used to construct the corresponding precision contribution for the second-stage weight matrix W. The second-stage mixed model then analyzes the adjusted means while retaining this first-stage precision information.

##########
## stage 1
## use mmes for dense field trials
##########
data(DT_h2, package="enhancer")
DT <- DT_h2
head(DT)

##                 Name     Env Loc Year     Block y
## 1            W8822-3 FL.2012  FL 2012 FL.2012.1 2
## 2            W8867-7 FL.2012  FL 2012 FL.2012.2 2
## 3           MSL007-B MO.2011  MO 2011 MO.2011.1 3
## 4         CO00270-7W FL.2012  FL 2012 FL.2012.2 3
## 5 Manistee(MSL292-A) FL.2013  FL 2013 FL.2013.2 3
## 6           MSM246-B FL.2012  FL 2012 FL.2012.2 3

envs <- unique(DT$Env)
BLUEL <- list()
XtXL <- list()
for(i in 1:length(envs)){
  ans1 <- mmes(y~Name-1,
               random=~Block,
               verbose=FALSE,
               computeCi = 2,
               data=droplevels(DT[which(DT$Env == envs[i]),])
  )
  ans1$Beta$Env <- envs[i]

  BLUEL[[i]] <- data.frame( Effect=factor(rownames(ans1$b)),
                            Estimate=ans1$b[,1],
                            Env=factor(envs[i]))
  # to be comparable to 1/(se^2) = 1/PEV = 1/Ci = 1/[(X'X)inv]
  XtXL[[i]] <- solve(ans1$Ci[1:nrow(ans1$b),1:nrow(ans1$b)])
}

## Solver selected: cholmod
## Solver selected: cholmod
## Solver selected: cholmod
## Solver selected: cholmod
## Solver selected: cholmod
## Solver selected: cholmod
## Solver selected: cholmod
## Solver selected: cholmod
## Solver selected: cholmod
## Solver selected: cholmod
## Solver selected: cholmod
## Solver selected: cholmod
## Solver selected: cholmod
## Solver selected: cholmod
## Solver selected: cholmod

DT2 <- do.call(rbind, BLUEL)
OM <- Reduce(adiag1,lapply(XtXL,as.matrix))

##########
## stage 2
## use mmes for sparse equation
##########
m <- matrix(1/var(DT2$Estimate, na.rm = TRUE))

ans2 <- mmes(Estimate~Env, henderson=TRUE,
             random=~ Effect + Env:Effect,
             rcov = ~ vsm(
               ism(units),
               sigma2 = 1,
               fixedSigma2 = TRUE
             ),
             W=OM,
             verbose=FALSE,
             data=DT2
)

## Solver selected: ldlt

## Using the weights matrix

summary(ans2)$varcomp

##                                              term parameter estimate  StdError
## 1                                vsm(ism(Effect))    sigma2 2.076894 0.5759343
## 2                            vsm(ism(Env:Effect))    sigma2 3.337166 0.3708767
## 3 vsm(ism(units), sigma2 = 1, fixedSigma2 = TRUE)    sigma2 1.000000 0.0000000
##     Zratio
## 1 3.606129
## 2 8.998047
## 3       NA

Literature

Covarrubias-Pazaran G. 2016. Genome assisted prediction of quantitative traits using the R package sommer. PLoS ONE 11(6):1-15.

Covarrubias-Pazaran G. 2018. Software update: Moving the R package sommer to multivariate mixed models for genome-assisted prediction. doi: https://doi.org/10.1101/354639

Bernardo Rex. 2010. Breeding for quantitative traits in plants. Second edition. Stemma Press. 390 pp.

Gilmour et al. 1995. Average Information REML: An efficient algorithm for variance parameter estimation in linear mixed models. Biometrics 51(4):1440-1450.

Henderson C.R. 1975. Best Linear Unbiased Estimation and Prediction under a Selection Model. Biometrics vol. 31(2):423-447.

Kang et al. 2008. Efficient control of population structure in model organism association mapping. Genetics 178:1709-1723.

Lee, D.-J., Durban, M., and Eilers, P.H.C. (2013). Efficient two-dimensional smoothing with P-spline ANOVA mixed models and nested bases. Computational Statistics and Data Analysis, 61, 22 - 37.

Lee et al. 2015. MTG2: An efficient algorithm for multivariate linear mixed model analysis based on genomic information. Cold Spring Harbor. doi: http://dx.doi.org/10.1101/027201.

Maier et al. 2015. Joint analysis of psychiatric disorders increases accuracy of risk prediction for schizophrenia, bipolar disorder, and major depressive disorder. Am J Hum Genet; 96(2):283-294.

Rodriguez-Alvarez, Maria Xose, et al. Correcting for spatial heterogeneity in plant breeding experiments with P-splines. Spatial Statistics 23 (2018): 52-71.

Searle. 1993. Applying the EM algorithm to calculating ML and REML estimates of variance components. Paper invited for the 1993 American Statistical Association Meeting, San Francisco.

Yu et al. 2006. A unified mixed-model method for association mapping that accounts for multiple levels of relatedness. Genetics 38:203-208.

Tunnicliffe W. 1989. On the use of marginal likelihood in time series model estimation. JRSS 51(1):15-27.

Giovanny Covarrubias-Pazaran

2026-10-06
